W1GHZ Guide to 5.76 GHz

Articles from QEX and other publications



• A 5760 Primer (KK7B), Proceedings of the 1991 Central States VHF Conference,
• A Single-Board Bilateral 5760-MHz Transverter (KK7B), QST, October 1990, pp. 27-31.
• Dual Mixer for 5760 MHz with Filter and Amplifier (N1BWT), QEX, August 1995, p. 9.

  Waveguide filter for 5.76 GHz


• High-Performance Antennas for 5760 MHz (N1BWT), QEX, January 1995, pp. 18-21.
  (reprinted in Proceedings of the 1995 (21st) Eastern VHF/UHF Conference)

  Clavin feed for 5.76 GHz


• A Modular, High-Performance 5.76 GHz Transverter (NJ2L), QEX, March 1995, p. 13.
  (reprinted in Proceedings of the 1995 (21st) Eastern VHF/UHF Conference)
• A 5616-MHz Local Oscillator (KH6CP/1),
• 5760 MHz from the Junkbox (N2SB), QEX, May 1994, pp. 20-24.
  (reprinted in Proceedings of the 1995 (21st) Eastern VHF/UHF Conference)
• PHEMPT Preamplifier for 6 cm. (DJ9BV), QEX, March 1996, pp. 21-24.
• A Low-Noise PHEMT Amplifier for 5760 MHz (KH6CP/1), QEX, Sept. 1994, pp. 28-31.
  (reprinted in Proceedings of the 1995 (21st) Eastern VHF/UHF Conference)
• Mixers, etc., for 5760 Mhz (N1BWT), Proceedings of Microwave Update '92, pp. 71-79.
• A Triband Microwave Dish Feed (WA3RMX), QST, Aug. 1990, pp. 23-27.
• VE4MA 5760 MHz Linear Polarization Feedhorn (VE4MA), Proceedings of Microwave Update '95, pp.
• 5760 MHz Linear Polarization Feedhorn with WR-137 Flange (WB5LUA), Proceedings of Microwave Update '95, pp.
• 5.7 GHz HPAs uning IM5964-3A (JE1AAH), Proceedings of Microwave Update '94, pp. 71-79.
• PHEMT Amplifiers for 2.3, 3.4, and 5.7 GHz (VE4MA), Proceedings of Microwave Update '92, pp.
• Phase Lock Source Update (K0KE) Proceedings of Microwave Update '87, pp. 93-95.
• Surplus Microwave Local Oscillators, Evaluating and Modifying Them (WD4MBK), Proceedings of Microwave Update '88, pp. 33-41.
• Phase-Locked Microwave Sources (AA5C) Proceedings of Microwave Update '91, pp. 113-136.
